Domestic Electricity Meters, generation M
- 1-phase residential meter
- Prepared for Smart Home applications
- Optimised for Smart Metering systems
- Secured against tampering
- Resistant to errors in the supply network
- Ultra-low power consumption
- 3-phase residential meter
- Prepared for Smart Home applications
- Optimised for Smart Metering systems
- Secured against tampering
- Resistant to errors in the supply network
- Ultra-low power consumption
OMNIPOWER
Top 5 features of the OMNIPOWER electricity meter
The OMNIPOWER single-phase and three-phase smart meters are for residential applications. As a high-end smart meter, equipped with a wide range of communication modules, it offers the standard features of a genuine smart meter like 4-quadrant metering, power quality registration and remote disconnect.
OMNIPOWER 1-phase
Residential meter prepared for smart home applications, secured against tampering, remote firmware upload and ultra low power consumption. DLMS/COSEM and EN 62056-21 protocol. Optional cover, short (00 mm) or 60 mm
Residential meter prepared for smart home applications, secured against tampering, remote firmware upload and ultra low power consumption. DLMS/COSEM and EN 62056-21 protocol. Optional cover, short (00 mm) or 60 mm
Communication Modules
S0 supply : Sends 24 V via a 2-wire and pulses by drawing the voltage to 0 V at each pulse. Can supply e.g. MULTICAL®.
Serial : Serial RS-485 or RS-232 communication or current loop with pulse inputs, tariff inputs or load control.
M-Bus : Reading via wireless or wired M-Bus system.
TCP/IP : Collection of consumption data via TCP/IP communication.
GSM/GPRS : Collection of consumption data via GSM/GPRS communication. Supports SMS reading.
Radio : Collection of consumption data via radio-based communication.
Primary Modules for OMNIPOWER
IP101i Module, 8 pin
5A Load Control Module
M-Bus Module, 8 pins with secondary addressing
2x5A Relay Module
RS485 Module, Multidrop
Data/Pulse module, Dual Pulse, 9600
4-Tariff Module, Current Loop, 9600
4-Tariff Module
OMNICON MUC Module for RF Meters
GSM8i 2G Module (for external systems)
GSM8i 2G with Antenna + MUC Add-On (for external systems)
GSM8i 2G with 2x5A Load Control Add-On Module (for external systems)
GSM3P (for external system) Alarm, no data call
OMNICON 2G Modem Module (For KAMSTRUP OMNIA System)
OMNICON 2G Modem Module with Antenna + MUC Add-On Module (For KAMSTRUP OMNIA System)
OMNICON 2G Modem + Earth Fault Module
Summation Transformer for Earth Fault Detection*
Installing SIM-CARD in GSM Module**
* To be used with Earth Fault Module ** Handling fee per SIM-CARD
Add-On Modules for OMNIPOWER
MUC for GSM8i 2G for Generation L and M*
RS485 Add-On for GSM8i 2G/3G
2x5A Load Control Module, Add-on for GSM8i
OMNICON MUC for OMNICON 2G Modem**
Software
- Configuration SW, METERTOOL
Various
- Standard meter cover
- Long meter cover, 60mm
- Optical reading head with USB plug
- Optical reading head with 9-pole D-sub connector
- METERTOOL kit for CT ratio programming
