Commercial and industrial electricity metering
Transformer-coupled electricity meters from Kamstrup are electronic meters of the highest quality. The meters can be equipped with a wide range of communication technologies, and the robust design makes them especially suitable for commercial and industrial customers.
OMNIPOWER CT is a 3-phased current transformer electricity meter for registration of electric energy. The meter is fully electronic without movable parts. Thus, energy registration is not affected by shock or impact during transport and mounting. Furthermore, measurements are correct no matter the physical mounting direction.
Modules for
Kamstrup 351C can be supplied and retrofitted with communication modules. The modules function as inputs and outputs for the meter. Mounting of modules does not require subsequent verification of the meter.
Communication Modules
S0 supply : Sends 24 V via a 2-wire and pulses by drawing the voltage to 0 V at each pulse. Can supply e.g. MULTICAL®.
Serial : Serial RS-485 or RS-232 communication or current loop with pulse inputs, tariff inputs or load control.
M-Bus : Reading via wireless or wired M-Bus system.
TCP/IP : Collection of consumption data via TCP/IP communication.
GSM/GPRS : Collection of consumption data via GSM/GPRS communication. Supports SMS reading.
Module for 351C Primary Modules for 351C
S0 Supply Module
IP101i Module, 8 pin
Pulse input and load Control Module
5A Load Control Module
Z-Wave Slave Module
M-Bus Module, 8 pins with secondary addressing
2x5A Relay Module
MUC for RF for Generations L and M
RS485 Module, Multidrop
Data/Pulse module, Dual Pulse,9600
4-Tariff Module, Current Loop, 9600
4-Tariff Module
RadioRouter Module 50mW, Senea Encrypted 433.460 MHz SE
RadioRouter Module 50mW, Senea Encrypted 433.920 MHz SE
RadioRouter Module 50mW, Senea Encrypted 434.390 MHz SE
RadioRouter Module 50mW, Senea Encrypted 444.000 MHz SE
RadioRouter Module 50mW, Senea Encrypted 444.050 MHz SE
RadioRouter Module 50mW, Senea Encrypted 444.400 MHz SE
RadioRouter Module 50mW, Senea Encrypted 444.700 MHz SE NO
RadioRouter Module 50mW, Senea Encrypted 444.300 MHz SE FI
GSM8i 3G Module
GSM8i 3G Module with 2x5A Load Control + Antenna Add-On
GSM8i 3G with with MUC + Antenna Add-On
GSM8i 3G with with RS485 Add-On Module
GSM8i RF 3G Module (+a free choice of external antenna to be added to the price)
GSM8i 2G Module
GSM8i 2G with Antenna + MUC add-on
GSM8i 2G with 2x5A Load Control Add-on Module
GSM8i 2G with with RS485 Add-On Module
Installing SIM-CARD in GSM Module**
* Only for Kamstrup Legacy Systems ** Handling fee per SIM-CARD
Add-On Modules for 351C
2x5A Load Control Module, Add-on for GSM8i 3G
MUC for GSM8i 2G for Generation L and M*
RS485 Add-On for GSM8i 2G/3G
2x5A Load Control Module, Add-on for GSM8i 2G
Software
- Configuration SW, METERTOOL
Various
- Standard meter cover
- Long meter cover, 60mm
- Optical reading head with USB plug
- Optical reading head with 9-pole D-sub connector
- METERTOOL kit for CT ratio programming
